Your C enum might be 1 byte

Enums look like the least interesting feature of C. You list a few names, the compiler numbers them from zero, and you move on.

Until a struct shared between your firmware and a desktop tool stops lining up, and the culprit is a three-value enum that takes one byte on one side and four on the other. Same names, same values, different storage.

Here’s what the C standard promises about enums, what compilers do with the freedom it leaves them, and how to keep enums from breaking your ABI. All output comes from GCC 15.3 and Clang 21.1 on x86-64 Linux, and the Arm GNU Toolchain 14.3 targeting a Cortex-M4.

Two Things Called “Enum”

#

enum color { RED, GREEN, BLUE };

This one line declares two different things:

• Enumeration constants: RED, GREEN and BLUE. Up to C17, they are always int.
• An enumerated type: enum color. This is what ends up in memory.

The standard pins down the first and leaves the second open (C17 §6.7.2.2):

Each enumerated type shall be compatible with char, a signed integer type, or an unsigned integer type. The choice of type is implementation-defined, but shall be capable of representing the values of all the members of the enumeration.

So sizeof(RED) is always sizeof(int), but sizeof(enum color) can be 1, 2, 4 or 8 bytes, stored exactly like whichever integer type the compiler picked.

What GCC, Clang and MSVC Choose

#

Since an enumerated type is compatible with exactly one integer type, C11’s _Generic can name it. Every table in this post comes from this probe:

#define TYPE_NAME(x) _Generic((x),               \
    char:               "char",                  \
    signed char:        "signed char",           \
    unsigned char:      "unsigned char",         \
    short:              "short",                 \
    unsigned short:     "unsigned short",        \
    int:                "int",                   \
    unsigned int:       "unsigned int",          \
    long:               "long",                  \
    unsigned long:      "unsigned long",         \
    long long:          "long long",             \
    unsigned long long: "unsigned long long",    \
    default:            "something else")

printf("enum color: %s, %zu bytes\n",
       TYPE_NAME((enum color)0), sizeof(enum color));
printf("RED: %s, %zu bytes\n", TYPE_NAME(RED), sizeof(RED));

GCC and Clang use unsigned int unless a value is negative, and int otherwise. On x86-64 with default flags:

The constants stay int in every case. MSVC keeps it simple: a C enum there is always a 4-byte int.

Short Enums

#

-fshort-enums makes GCC and Clang pick the smallest type that fits, signed only if a value is negative:

Here’s BLUE (2) in memory on a little-endian machine:

default:        02 00 00 00
-fshort-enums:  02

The constants don’t shrink, so now sizeof(enum color) != sizeof(RED). The alignment does, so every struct containing the enum changes layout. GCC’s manual is blunt about it: the flag “causes GCC to generate code that is not binary compatible with code generated without that switch.” To shrink a single enum instead, GCC and Clang accept __attribute__((packed)) on the type. Packed enums will get their own post.

On Arm, Short Enums Are the Default

#

The Arm procedure call standard (AAPCS) leaves enum size to the platform ABI: either a word, or “the smallest integer type that can contain all of its enumerated values.” Bare-metal arm-none-eabi-gcc picks the second, no flags needed:

$ arm-none-eabi-gcc -mcpu=cortex-m4 -mthumb -c globals.c
$ arm-none-eabi-nm -S globals.o
00000000 00000001 B g_color
00000001 00000001 B g_delta
00000002 00000002 B g_wide

That’s 1, 1 and 2 bytes, without anyone asking for it. Other Arm toolchains chose differently:

The good news is that every Arm object file records its choice:

$ arm-none-eabi-readelf -A globals.o | grep enum
  Tag_ABI_enum_size: small

With -fno-short-enums the tag reads int, so the GNU linker can warn you when you mix the two: warning: vendor.o uses 32-bit enums yet the output is to use variable-size enums; use of enum values across objects may fail. x86-64 has no such tag, and its linker stays silent.

C23: Choosing the Type Yourself

#

C23 lets you fix the underlying type, with the syntax C++11 introduced:

enum status : uint8_t { ST_OK, ST_ERR };

enum status is now 1 byte with every compiler and every flag, -fshort-enums included. The constants take the enum’s type too, so sizeof(ST_OK) is 1 as well. GCC supports this from version 13, and Clang from version 20 (or as an extension in older language modes).

C23 also lets enumerator values exceed int:

enum big { B_SMALL = 0, B_HUGE = 0x100000000 };

On x86-64, enum big becomes an 8-byte unsigned long, and every constant, B_SMALL included, takes the enum’s type.

Where Enum Size Leaks into Your ABI

#

Enum size becomes part of your ABI the moment an enum crosses a boundary: a struct shared with another binary, a wire format, a file in flash, or memory shared between cores. Take a record that Cortex-M firmware sends to a desktop tool:

enum channel { CH_EEG, CH_EMG, CH_ECG };

struct sample {
    enum channel ch;
    uint8_t      gain;
    uint16_t     value;
};

Same header, two layouts. Send sizeof(struct sample) bytes over BLE, cast the buffer on the other side, and gain and value come out as garbage. Neither compiler did anything wrong.

Rules I Follow

#

• Never assume a size, not 4 and not 1. If your code depends on a layout, let the compiler check it:

  _Static_assert(sizeof(struct sample) == 4,
                 "struct sample layout changed: check enum size");


• Keep enums out of anything that crosses a boundary. Store a fixed-width integer like uint8_t ch and use the enum only for its values, or use enum channel : uint8_t in C23.

• Build everything with the same enum setting, vendor libraries included. On Arm, make the enum-size warning fatal with -Wl,--fatal-warnings.

• Range-check with one unsigned comparison: (unsigned)c < COUNT.

Inside a single build, the names are all you need. Once an enum crosses a boundary, you need to know how big it is, and the only reliable way is to choose it yourself.
