Packed enums vs -fshort-enums

In the previous post, we saw that -fshort-enums tells GCC and Clang to give every enum the smallest type that fits, and I promised packed enums their own post.

Your C enum might be 1 byte

7 mins

Embedded Programming Languages C ABI

What the C standard promises about enums, what GCC, Clang, MSVC and Arm compilers actually do with that freedom, and how to keep enums from breaking your ABI.

__attribute__((packed)) does the same thing for a single enum, and GCC’s manual says the two are equivalent:

When attached to an enum definition, the packed attribute indicates that the smallest integral type should be used. Specifying the -fshort-enums flag on the command line is equivalent to specifying the packed attribute on all enum definitions.

Same rule, same sizes. The difference is where the decision lives: in a flag that changes every enum the compiler sees, or in the header, on the one type that needs it.

As before, the output comes from GCC 15.2 and Clang 21.1 on x86-64 Linux, and the Arm GNU Toolchain 14.3 targeting a Cortex-M4.

Why Shrink an Enum?

#

On a microcontroller, three wasted bytes per enum add up. Take a state machine that tracks 64 channels:

enum state { IDLE, RUN, STOP, STATE_COUNT };

enum state table[64];

enum state next_state(enum state s)
{
    return (enum state)((s + 1) % STATE_COUNT);
}

On a Cortex-M4 with -O2, a 1-byte enum puts table in 64 bytes of .bss instead of 256. The price is a single uxtb in next_state(), which truncates the arithmetic back to a byte. Reading the table costs nothing extra: it’s an ldrb instead of an ldr.

Same Rule, One Type at a Time

#

enum __attribute__((packed)) color { RED, GREEN, BLUE };

Apply packed to the three enums from the previous post and you get exactly the -fshort-enums results on GCC and Clang: unsigned char, signed char and unsigned short, for 1, 1 and 2 bytes. As with short enums, the constants stay int. Using both does no harm: under -fshort-enums, packed changes nothing.

Where the Attribute Goes

#

enum __attribute__((packed)) a { A0, A1 };            /* 1 byte */
enum b { B0, B1 } __attribute__((packed));            /* 1 byte */
typedef enum { C0, C1 } __attribute__((packed)) c_t;  /* 1 byte */
enum [[gnu::packed]] d { D0, D1 };                    /* 1 byte, C23 syntax */

typedef enum { E0, E1 } e_t __attribute__((packed));  /* 4 bytes, with a warning */
__attribute__((packed)) enum f { F0, F1 };            /* 4 bytes, GCC says nothing */

After the typedef name, both compilers warn that the attribute is ignored. Before the enum keyword, Clang warns by default and even suggests the fix:

warning: attribute 'packed' is ignored, place it after "enum" to apply attribute to type declaration [-Wignored-attributes]

The Decision Lives in the Header

#

-fshort-enums is invisible in the source. You can’t tell the size of an enum in a header without checking how every project that includes it is built, and the flag also changes the enums in system and vendor headers. packed is part of the type, so every GCC or Clang build that includes the header gets the same size. Here’s sizeof(struct sample) from the previous post, with a plain and a packed enum channel:

The firmware and the desktop tool finally agree, and nobody had to touch their build flags.

What the Arm Linker Sees

#

A packed enum doesn’t change the Tag_ABI_enum_size build attribute, because the tag records the build flag, not the types in the file:

$ arm-none-eabi-gcc -mcpu=cortex-m4 -mthumb -fno-short-enums -c packed.c
$ arm-none-eabi-readelf -A packed.o | grep enum
  Tag_ABI_enum_size: int
$ arm-none-eabi-nm -S packed.o
00000000 00000001 D g_color

For packed enums that’s fine, since both sides read the size from the header. But it makes the linker’s check coarse. An empty main() built with -fno-short-enums and linked against the toolchain’s own C library already trips it:

$ arm-none-eabi-gcc -mcpu=cortex-m4 -mthumb -fno-short-enums --specs=nosys.specs main.c
ld: warning: /tmp/ccUxEXzc.o uses 32-bit enums yet the output is to use variable-size enums; use of enum values across objects may fail

There isn’t a single enum in the file, yet the warning fires on every build. On bare-metal Arm, leave the default alone and size specific types in the source instead.

What Packed Doesn’t Do

#

It doesn’t promise one byte

#

packed means “the smallest type that fits”, and that changes when the enum changes:

enum __attribute__((packed)) opcode { OP_NOP, OP_READ, OP_WRITE, OP_VENDOR = 256 };
_Static_assert(sizeof(enum opcode) == 1, "enum opcode must fit in one byte");

Without the assert, enum opcode silently becomes a 2-byte unsigned short, even with -Wall -Wextra -Wpedantic, and every struct that contains it changes layout. The same assert also catches a misplaced attribute, and a compiler that ignores it.

It truncates values that don’t fit

#

enum __attribute__((packed)) color { RED, GREEN, BLUE, COLOR_COUNT };

uint16_t raw = 0x0102;           /* corrupted field, should be 0 to 2 */
enum color c = (enum color)raw;  /* c == BLUE */

The high byte is dropped, and the corrupted value passes the (unsigned)c < COLOR_COUNT check from the previous post as a valid BLUE. With a 4-byte enum, c would be 258 and the check would reject it. Without the cast, Clang warns under -Wconversion; GCC doesn’t. Check the raw integer before it becomes an enum:

if (raw >= COLOR_COUNT)
    return false;

Forcing 32 Bits

#

For the opposite, an enum that stays 4 bytes under any flag, add a value that only fits in 32 bits. CMSIS-RTOS2 does this in most of its enums:

typedef enum {
  osOK                    =  0,
  osError                 = -1,
  /* ... */
  osStatusReserved        = 0x7FFFFFFF  ///< Prevents enum down-size compiler optimization.
} osStatus_t;

Different RTOS kernels and compilers implement this API, and the sentinel keeps osStatus_t at 4 bytes for all of them.

The cost is a value that can never happen, but -Wswitch still wants it handled:

warning: enumeration value 'osStatusReserved' not handled in switch [-Wswitch]

Portability and C23

#

MSVC doesn’t support __attribute__, so a portable header needs a macro. The assert catches any compiler where the macro expands to nothing:

#if defined(__GNUC__) || defined(__clang__)
#  define ENUM_PACKED __attribute__((packed))
#else
#  define ENUM_PACKED
#endif

enum ENUM_PACKED channel { CH_EEG, CH_EMG, CH_ECG };
_Static_assert(sizeof(enum channel) == 1, "enum channel must be 1 byte");

If all your compilers support C23, a fixed underlying type beats both. enum channel : uint8_t is exactly one byte under any flag, and a value that doesn’t fit is a compile error instead of a bigger type: in GCC’s words, enumerator value outside the range of underlying type.

Which One to Use

#

A uint8_t field is the most portable option, but the debugger shows numbers instead of names, and -Wswitch can’t check your switches.

Rules I Follow

#

Leave the enum-size flag alone. On x86-64 or bare-metal Arm, flipping it changes every enum in every header you include.

Shrink one type at a time, in the header, with a _Static_assert next to it. Use a C23 fixed type where you can, and packed where you can’t.

Range-check the raw integer, not the packed enum you converted it to.

Pin enums that cross a compiler boundary with fixed-width fields or a 0x7FFFFFFF sentinel.

Pascal apologised for a letter he hadn’t had time to make shorter. Enums have the opposite problem: one flag makes them all shorter, and that’s exactly what makes it dangerous. Taking the time to shrink them one at a time, each with an assert, is what keeps them the same size in every build.
